I've seen people have 4 leds in a translucent controller. I want to do something like this but i dont kno how. i know how to put in one but how would u get 4 leds into different spots of the controller

#2 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 01 April 2004 - 07:13 PM

Ben999 has done it but he hasnt made a tutoril but he had like around 8 leds i beleive

#3 brahm2

brahm2

    Internet Superstar

  • Members
  • PipPipPipPipPipPipPipPipPipPip
  • 6,003 posts
  • Location:Saskatchewan, Canada
  • Interests:I'm an EE student at the UofS in Saskatoon. I love guitar and drinking beer.. sometimes both.
  • Xbox Version:v1.0
  • 360 version:none

Posted 01 April 2004 - 10:22 PM

There are tons of tuts for power sources and how to wire them, but I don't think there is one that covers placement of LEDs. Just secure them in place wherever you can.

Check mysig for links on LED wiring smile.gif

#4 therobman

therobman

    X-S Senior Member

  • XS-BANNED
  • PipPip
  • 184 posts
  • Xbox Version:unk
  • 360 version:unknown

Posted 01 April 2004 - 10:31 PM

user posted image


here mine they are a bitch to fit in place but it looks hot

#5 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 01 April 2004 - 10:38 PM

I love it lol I wanna do it to my green see through controller if any of you have done it and have a mini tutorial or something or somepictures on how to wire it please post in here smile.gif

#6 Ghost_Face_Killah

Ghost_Face_Killah

    X-S Senior Member

  • Members
  • PipPip
  • 189 posts
  • Xbox Version:unk
  • 360 version:unknown

Posted 01 April 2004 - 10:41 PM

ya but how do you make them stay where you want it. any suggestions?

#7 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 01 April 2004 - 10:47 PM

Hot Glue my guess

#8 brahm2

brahm2

    Internet Superstar

  • Members
  • PipPipPipPipPipPipPipPipPipPip
  • 6,003 posts
  • Location:Saskatchewan, Canada
  • Interests:I'm an EE student at the UofS in Saskatoon. I love guitar and drinking beer.. sometimes both.
  • Xbox Version:v1.0
  • 360 version:none

Posted 01 April 2004 - 10:48 PM

Hot glue?

Most of my controller LEDs just stay in place by how they are placed - either soldered directly onto power points, or the wires are arranged to hold them in place.

#9 therobman

therobman

    X-S Senior Member

  • XS-BANNED
  • PipPip
  • 184 posts
  • Xbox Version:unk
  • 360 version:unknown

Posted 01 April 2004 - 10:49 PM

yea hot glue if any one wants this controller im selling it b/c im modding a blue one check my bst in my sig

#10 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 01 April 2004 - 10:54 PM

I would wan't to be safe and put a dab of hot glue barely any and iitll be secure and you wont worry

Edited by Xboxman20, 01 April 2004 - 11:03 PM.


#11 Ghost_Face_Killah

Ghost_Face_Killah

    X-S Senior Member

  • Members
  • PipPip
  • 189 posts
  • Xbox Version:unk
  • 360 version:unknown

Posted 01 April 2004 - 10:57 PM

I use 30 awg wire, because thats all I have. I don't think the leds will stay in place with a wire that skinny. uhh.gif

#12 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 01 April 2004 - 11:04 PM

I have 22 lol Its small enough for the controller


#13 lalaland

lalaland

    X-S Member

  • Members
  • Pip
  • 84 posts

Posted 02 April 2004 - 12:23 AM

so the best wire is 22. where u get it. radio shack homedepot...

#14 Xboxman20

Xboxman20

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,945 posts
  • Location:Palmdale, CA
  • Xbox Version:v1.0

Posted 02 April 2004 - 12:31 AM

No No No its not the best im just saying its small enough for a lot of mods in the xbox I was looking at it today I need to find uses for it now lol.

#15 Ben999_

Ben999_

    X-S Freak

  • Members
  • PipPipPipPipPip
  • 1,919 posts
  • Location:Lebanon, PA, USA
  • Xbox Version:v1.0
  • 360 version:unknown

Posted 02 April 2004 - 12:35 AM

I use a combination of Brahm's method and hot glue to fit the most inside. There are 9 LED's in my blue controller right now, but I haven't tried to install as many as possible. I could probably fit twice that many inside. Anyway, try to minimize your wires by sharing connections with the LED's and combine the 5v and ground connections coming in from your power source. If you run wires from each LED it will get much too messy.

user posted image

user posted image
